VID HD90

Key Features

Input : HDMI 1.4 , SDI input, DVI input, S-VIDEO input, MMI Cable iniput(VGA,YpBpr,RCA)
MIC input, Line input ( sound mixing) , Line output (headphones or loudspeaker) ,Foot Pedal input Output : HDMI (pass-through) up to 1080P60
Support Foot Control for medical use
Capture resolution up to 1080p 60FPS
Capture format : H.264 MP4
Sampling rate : 48kHz PCM Stream and record your Xbox, PlayStation, or Wii U gameplay. 1080p quality with 60 fps

Specification

HDMI / SDI/ DVI/ VGA/ Component(YPBPR)/Composite(AV)/S-VIDEO Video input supports		4K2K (3840×2160 30p), 1920×1080 (60p, 50p, 25p, 24p, 30p, 60i, 50i), 1360×768 (60p), 1280×1024 (60p), 1280×720 (60p), 1280×768 (60P), 1280×800 (60p), 1024×768 (60p),720×480 (60p, 60i, 50i), 640×480(60p), 720×576 (50p)
Record Resolution		1920×1080(60p),1280×720(60p),1024×768(60p),1280×800(60p)
I/O Interface	Input	HDMI in, SDI in, DVI in,S-Video in,MMI in (YPBPR,VGA,RCA)MIC in, LINE in, Power in (12V/1.5A). Foot(Foot Pedal for recorder or snapshot)
	Output	HDMI out Line out, SD Slot1: SD (FAT32, NTFS, MAX 512G) USB Type A1: Flash Max 512G, hard disk (FAT32, NTFS, exFAT tec MAX 8T) TYPEC*1: connect to windows PC for live-streaming (OBS)
Adapter Voltage		Input 100~240V 50/60Hz, Output 12V/1.5A
Working temperature		0 to 50℃
Power consumption		Less than 18W
Reserve temperature		-20 to +60℃

System Requirements

Windows® 10 / Windows 8.1 / Windows 7 (SP1)
Computer: Intel® Core™ i5-4440 3.10 GHz + NVIDIA GeForce GTX 660 or above
8 GB RAM or above
System compatible

Support 3rd party

OBS (Windows, Mac)

Support Standalone Recorder

SD Slot*1: SD (FAT32, NTFS, exFAT MAX 512G)

USB Type A*1:

Flash Max 512G, hard disk

(FAT32, NTFS, exFAT，GPT，MBR MAX 8T)

Package Contents

HD90 All-in-One Video Recorder
HDMI cable *1
MMI cable *1
Type-c cable2.0 *1
Remote controller *1
Quick Start Guide
Adapter 12V/1.5A

※(The device does not contain a built-in battery. External battery sold separately. Compatible models: Sony NP-F550, F750, and F970 7.4V. You can also add a CR2032 battery – not included –to preserve the time & date setting on the device.)
