VEX-T1201T

UHD+ HDMI over Category Cable Transmitter

Point to point extension for audio and video
Transmitter has HDMI local Loop out
Receiver can switch video and audio sources between local HDMI input and CAT input
CAT6/6A/7 Cable can reach to up to 60M
Supports POC (Power over Cable), transmitter powers compatible receiver
Multi-channel audio compliant for PCM7.1 up to 192KHz, AC-3(Dolby5.1), and DTS 5.1
EDID can switch among 4 modes: Sink EDID, FHD, UHD, and UHD+

The UHD+ HDMI over Category Cable Transmitter is able to extend HDMI signals and transmit UHD video and audio signals through a single CAT6/6A/7 network cable. The transmission distance can be up to 60m per segment, allowing the user to cascade the system without signal loss or introducing delay.

Interfaces
Input Port	1 HDMI (Type A)
Output Port	1 HDMI(Type A) 1 CAT6(RJ-45)
Service Port	1 USB (Mini-B)

Video
HDMI Compliance	HDMI 2.0
HDCP Compliance	2.x
Input Signal Types	3840x2160p60 YUV 4:4:4
Output Signal Types	3840x2160p60 YUV 4:4:4
		Resolutions
Maximum Input	HDMI	3840x2160p60 YUV4:4:4
Maximum Output	HDMI	3840x2160p60 YUV4:4:4
	CAT 6/6A/7	3840x2160p60 YUV4:4:4

Audio
HDMI	LPCM (8 Channels), Bitstream

Power
Power Supply	12V/3A
Power Consumption	4.6W

Enclosure
Chassis Material	Plastic
Chassis Color	Black
Dimensions (W×H×D)	85mm×26mm×85mm [Case Only] 91mm×26mm×85mm [All Inclusive]
Weight	150g

Field Firmware Update
USB

ORDERING INFORMATION
Model No. Product Description
VEX-T1201R	UHD+ HDMI over Category Cable Receiver
VEX-T1201T	UHD+ HDMI over Category Cable Transmitter
