SDI2USB3

INOGENI’s SDI2USB3 video converter enables 3GSDI cameras to connect with computers, laptops or CODECs—without glitches or complicated setups.

  • 3GSDI professional video capture to USB 3.0
  • Highly stable signal
  • Active loop output connector
  • Cost-effective professional camera converter solution that is reliable and simple to install and connect (no driver required)
  • Compact and robust design with its aluminium enclosure
  • Designed and manufactured in Canada
  • TAA-compliant

APPLICATION

TECHSPECS

Input
Connector

1 x BNC (3GSDI input)

1 x BNC (3GSDI active loop out)
Video Resolution

3G: 1080p60/59.94/50 (Level A, B-Dual Link)

HD: 1080i60/59.94/50, 1080p30/29.97/25/24/23.98 and 720p60/59.94/50/30/29.97/25/24/23.98

SD: NTSC/PAL
Jitter (alignment) HD/SD: <0.2 UI 3 Gb/s: <0.4 UI
Cable Length

150m (492 ft.) at 1.485 Gb/s

120m (393 ft.) at 2.970 Gb/s
Frame Rates 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 Hz
Color Space 4:2:2
Sampling Rate 148.5/148.35 MHz
Embedded Audio Ch 1&2 48kHz LPCM
HDCP Copy Protection INOGENI will not decrypt BD/DVD movies, satellite/cable receivers or other encrypted sources.

Output
Connector 1 x USB 3.0
Codec

YUY2 4:2:2 8-bit for USB 3.0

MJPEG for USB 2.0*

* Devices having serial numbers >= SD2036XXX will support MJPEG over USB 2.0. Otherwise, it will be uncompressed video.
Video Scaler Automatic hardware based
Color Space Conversion Automatic hardware based
Sampling Conversion Automatic hardware based
Frame Rate Conversion Automatic hardware based
Audio 2-channel LPCM audio from SDI

Compatibility
Operating System

NO driver installation necessary

Windows 7 and above (32/64-bit)

Mac OSX 10.10 and above

Linux (kernel v2.6.38) and above
Host Requirements USB 3.0
Motherboard Compatible with all motherboards. Intel, Renesas, ASMedia, and Fresco Logic
Cameras Supported Cameras and camcorders with a SDI output
Software Compatibility UVC-compliant. Runs with all software compatible to DirectShow/MediaFoundation, V4L2, QuickTime and AVFoundation.
Note to VAR/INTEGRATORS – this data is organized by product and may be duplicated for inclusion in a design or bid specs. It does vary from converter to converter. If you would like the same data in a .doc or .txt format please let us know.
Dimensions & Weight 3.2” x 2.9” x 0.75” 139g
Operating Temperature 0° to 45° C (32° to 113° F)
Storage Temperature -40° to 105° C (-40° to 221° F)
Relative Humidity 0% to 90% non-condensing
USB Power 5V, 530 mA
UPC Code 040232250538
Origin Canada
