ez-DSK

ez-DSK allows easy application of subtitles, images, sequences, videos, and widgets over your video program.

Connect the ez-DSK to your PC (Windows OS) through USB 3.0 and send all your graphics created with our dedicated CG software "ez-CGER."

Key features of ez-DSK

Features that ez-DSK has are what power this CG generator. The ez-DSK gives you Zero Delay through its internal Fill & Key overlay application. It also has a Fail Safe mechanism to prevent catastrophic broadcasting disasters. At the same time, your video signals will be re-clocked with ez-DSK.

Fail Safe

Feel safe with ez-DSK's Fail Safe. Even when powered off, your broadcasting will continue (1 SDI output port), so do not worry about it malfunctioning during your live show.

Zero Delay

The ez-DSK overlays the CG over your video stream by internally processing the Key & Fill. It gives you Zero Delay to your broadcasting. On top of that, there is no need to spend an extra port of your switcher.

Distributor and Converter

There are 4 SDI output ports, 1 HDMI output port, and 1 SDI loop out port. You can add multiple monitors to the ez-DSK without the need of a distributor. (Or a SDI to HDMI converter for that matter).

Complimentary CG software

All Lumantek CG products come with their dedicated CG software, the "ez-CGER." This software has an easy user interface to learn. You will be a pro in no time.

ez-DSK

Input Ports

Video:

1 x SDI

Computer Graphics:

1 x USB 3.0

ez-DSK

Output Ports

Video:

1 x SDI (Loop Out)

4 x SDI (1 port has 'Fail Safe' mechanism)

1 x HDMI

Apply details to your CG

It is not easy to insert CG to your video unless of course you are a professional in the field using often expensive and sophisticated applications. ez-DSK and ez-CGER (the software) will make you able to apply details into your video easily. The user interface of the ez-CGER has the most commonly used program interfaces, and you will be able to learn its functions quite quickly. Unique function of ez-DSK is that you do not need Fill & Key as conventional CG devices. All you need is a PC with USB 3.0, and you video in SDI format.

*System requirements must be met.

ez-DSK

Overlay Type CG Generator

Specs

Data Input
SDI Input	(BNC 75 Ohms) x 1
SDI Input	1080p30/ 1080p29/1080p25/ 1080p24/ 1080p23/ 1080i60/ 1080i59/ 1080i50/ 720p60/ 720p59/ 720p50
CG Input	(USB3.0) x 1
CG Input	1080p30/ 1080p29/1080p25/ 1080p24/ 1080p23/ 1080i60/ 1080i59/ 1080i50/ 720p60/ 720p59/ 720p50

System

Requirement

OS : Windows7, Windows8, Windows10

CPU: Intel i7 4th Generation or above (Desktop)

Intel i7-7700HQ or above (Laptop)

RAM: 8GB

VGA: GeForce GTX 1050

USB 3.0 Host Controller

Data Output
SDI Output	(BNC 75 Ohms) x 4
SDI Output	1080p30/ 1080p29/1080p25/ 1080p24/ 1080p23/ 1080i60/ 1080i59/ 1080i50/ 720p60/ 720p59/ 720p50
SDI Loop Output	(BNC 75 Ohms) x 1 – Same as input resolution – Overlay feature is not supported
HDMI Output	(BNC 75 Ohms) x 1
HDMI Output	1080p30/ 1080p29/1080p25/ 1080p24/ 1080p23/ 1080i60/ 1080i59/ 1080i50/ 720p60/ 720p59/ 720p50

* ez-DSK cannot overlay graphic on 480i, 625i, Full HD (1080p50, 1080p59, 1080p60) formats.

Dimensions

3 x HDMI 1 x SDI (BNC, 75 Ohms)
