CE314-SN

דגם: CE314-SN Quad SDI PCIe Capture Card

No need for re-cabling

BNC connectors allow for easy installation of any HD-SDI and 3G-SDI source without extensive modifications to the existing cabling. This means that only front-end and back-end products need to be replaced when upgrading to an HD-SDI or 3G-SDI system. This cuts back on time and labor costs.

Low latency

Capturing stunning uncompressed raw data and recording it with almost zero latency is made possible with the CE314-SN Less than 50ms pass from the moment the video source is captured, encoded, transmitted, decoded and displayed. This low latency is particularly beneficial for applications that require real-time solutions.

Remarkable 60 frames per second

The most common consumer recording devices today support higher recording frame rates as do more professional recording devices, such as those used for medical imaging and industrial surveillance. At 60 frames per second, you can improve the quality of a wide range of media recorded for businesses, universities, broadcasting, and manufacturing facilities, providing a more lifelike and smooth video playback experience.

Hardware scaling, de-interlacing, and color space conversion

AVerMedia hardware-based video engine technology implements the most useful video processing functions, including scaling, de-interlacing, and color space conversion. This can significantly help you reduce the computing burden on software and hardware, which allows you to focus on other important parts of your application.

Host Interface PCIE Gen1 x 4
Audio Interface SDI Embedded Audio (8 Ch per input)
Audio Format PCM
Audio Sampling Rate 48KHz
Connector Type BNC
Input Interface HD-SDI / 3G-SDI
Video Format YUV 4:2:2
Color Depth 8-bit
Channel No. 4 Ch ( 4 Ch HD-SDI or
2 Ch 3G-SDI / 2 Ch HD-SDI )
Max. Input Resolution 1920 x 1080 60fps
Max. Recording Resolution HD-SDI 1920 x 1080 30fps
3G-SDI 1920 x 1080 60fps
Recording Mode Raw data
Low latency <50ms
Multi-Card Support Yes
Supported OS Windows 7/8.1/10 (32/64 bit)
Linux (32/64 bit)*
Dimensions (L x W) 135 mm x 100 mm
Form factor PCIE high profile
Power Consumption 16W
Operating Temperature 0°C ~ 40°C
Operating Humidity 5% – 80% Relative Humidity
Safety Certification CCC / FCC / CE

For an attractive quote and to order the product

Call : 972-3-6176888
